public class UserRealm extends AuthorizingRealm {

    private UserService userService;

    public void setUserService(UserService userService) {
        this.userService = userService;
    }

	// 从数据库中获取权限信息
    @Override
    protected AuthorizationInfo doGetAuthorizationInfo(PrincipalCollection principals) {
        String username = (String)principals.getPrimaryPrincipal();

        SimpleAuthorizationInfo authorizationInfo = new SimpleAuthorizationInfo();
		// 从数据库中查询当前用户所拥有的角色
        authorizationInfo.setRoles(userService.findRoles(username));
		// 从数据库中查询当前用户所拥有的权限
        authorizationInfo.setStringPermissions(userService.findPermissions(username));
        return authorizationInfo;
    }

	// 从数据库中获取认证信息
    @Override
    protected AuthenticationInfo doGetAuthenticationInfo(AuthenticationToken token) throws AuthenticationException {
        String username = (String)token.getPrincipal();
        User user = userService.findByUsername(username);
        if(user == null) {
            throw new UnknownAccountException();//没找到帐号
        }
        if(Boolean.TRUE.equals(user.getLocked())) {
            throw new LockedAccountException(); //帐号锁定
        }
        //交给AuthenticatingRealm使用CredentialsMatcher进行密码匹配，如果觉得人家的不好可以自定义实现
        SimpleAuthenticationInfo authenticationInfo = new SimpleAuthenticationInfo(
                user.getUsername(), //用户名 principal
                user.getPassword(), //密码   hashedCredentials
            	//注册的时候生成盐值   credentialsSalt
                ByteSource.Util.bytes(user.getCredentialsSalt()),//salt=username+salt
                getName()  //realmName
        );
        return authenticationInfo;
    }

}

public Object getObject() throws Exception {
    if (this.instance == null) {
        this.instance = this.createInstance();
    }

    return this.instance;
}

protected AbstractShiroFilter createInstance() throws Exception {
    log.debug("Creating Shiro Filter instance.");
    //1、安全管理器
    SecurityManager securityManager = this.getSecurityManager();
    //2、过滤器链管理器
    FilterChainManager manager = this.createFilterChainManager();
    //3、基于路径匹配的过滤器链解析器
    PathMatchingFilterChainResolver chainResolver = new PathMatchingFilterChainResolver();
    chainResolver.setFilterChainManager(manager);
    //返回shirofilter对象到spring容器中
    return new ShiroFilterFactoryBean.SpringShiroFilter((WebSecurityManager)securityManager, chainResolver);
}

public void setFilterChainDefinitions(String definitions) {
    Ini ini = new Ini();
    ini.load(definitions);
    //section key为url,value 为filter名称
    Section section = ini.getSection("urls");
    this.setFilterChainDefinitionMap(section);
}

protected FilterChainManager createFilterChainManager() {
    //创建DefaultFilterChainManager，添加默认的filters到manager
    DefaultFilterChainManager manager = new DefaultFilterChainManager();
    //设置默认Filter的基本属性
    Map<String, Filter> defaultFilters = manager.getFilters();
    for (Filter filter : defaultFilters.values()) {
        	//设置相关FilterURL的loginurl,successurl,unauthorizedUrl属性
            applyGlobalPropertiesIfNecessary(filter);
        }
    //获取在spring配置文件中的配置的Filter，eg:logout
    Map<String, Filter> filters = getFilters();
    if (!CollectionUtils.isEmpty(filters)) {
        for (Map.Entry<String, Filter> entry : filters.entrySet()) {
            String name = entry.getKey();
            Filter filter = entry.getValue();
            applyGlobalPropertiesIfNecessary(filter);
            if (filter instanceof Nameable) {
                ((Nameable) filter).setName(name);
            }
            // 将配置的Filter添加至manager中，如果同名Filter已存在则覆盖默认Filter
            manager.addFilter(name, filter, false);
        }
    }
    //配置的FilterChainDefinition
    Map<String, String> chains = this.getFilterChainDefinitionMap();
    if (!CollectionUtils.isEmpty(chains)) {
        for (Map.Entry<String, String> entry : chains.entrySet()) {
            String url = entry.getKey();
            String chainDefinition = entry.getValue();
            // 为配置的每一个URL匹配创建FilterChain定义，
            // 这样当访问一个URL的时候，一旦该URL配置上则就知道该URL需要应用上哪些Filter
            // 由于URL配置符会配置多个，所以以第一个匹配上的为准，所以越具体的匹配符应该配置在前面，越宽泛的匹配符配置在后面
            manager.createChain(url, chainDefinition);
        }
    }
    return manager;
}

public DefaultFilterChainManager() {
    this.filters = new LinkedHashMap<String, Filter>();
    this.filterChains = new LinkedHashMap<String, NamedFilterList>();
    addDefaultFilters(false);
}

protected void addDefaultFilters(boolean init) {
    for (DefaultFilter defaultFilter : DefaultFilter.values()) {
        addFilter(defaultFilter.name(), defaultFilter.newInstance(), init, false);
    }
}

anon(AnonymousFilter.class),
authc(FormAuthenticationFilter.class),
authcBasic(BasicHttpAuthenticationFilter.class),
logout(LogoutFilter.class),
noSessionCreation(facion ico.class),
perms(PermissionsAuthorizationFilter.class),
port(PortFilter.class),
rest(HttpMethodPermissionFilter.class),
roles(RolesAuthorizationFilter.class),
ssl(SslFilter.class),
user(UserFilter.class);

protected void executeChain(ServletRequest request, ServletResponse response, FilterChain origChain){
    FilterChain chain = getExecutionChain(request, response, origChain);
    //获取过滤链：如FormAuthenticationFilter
    chain.doFilter(request, response);
}

public final void doFilter(ServletRequest request, ServletResponse response, FilterChain filterChain){
    String alreadyFilteredAttributeName = getAlreadyFilteredAttributeName();
    if ( request.getAttribute(alreadyFilteredAttributeName) != null ) {
        //已经执行过该过滤器
        filterChain.doFilter(request, response);
    } else if ( !isEnabled(request, response) ||shouldNotFilter(request) ) {
           //该过滤器不适合该请求
            filterChain.doFilter(request, response);
        } else {
            request.setAttribute(alreadyFilteredAttributeName, Boolean.TRUE);
            try {
                //执行该过滤器
                doFilterInternal(request, response, filterChain);
            } finally {
                // Once the request has finished, we're done and we don't
                // need to mark as 'already filtered' any more.
                request.removeAttribute(alreadyFilteredAttributeName);
            }
        }
}

public void init() throws Exception {
    WebEnvironment env = WebUtils.getRequiredWebEnvironment(getServletContext());
    //SecurityManager
    setSecurityManager(env.getWebSecurityManager());
    //FilterChainResolver
    FilterChainResolver resolver = env.getFilterChainResolver();
    if (resolver != null) {
        setFilterChainResolver(resolver);
    }
}

protected void doFilterInternal(ServletRequest servletRequest, ServletResponse servletResponse, final FilterChain chain) {
    final ServletRequest request = prepareServletRequest(servletRequest, servletResponse, chain);
    final ServletResponse response = prepareServletResponse(request, servletResponse, chain);
    final Subject subject = createSubject(request, response);
    //noinspection unchecked
    subject.execute(new Callable() {
        public Object call() throws Exception {
            updateSessionLastAccessTime(request, response);
            executeChain(request, response, chain);
            return null;
        }
    });
}

protected void executeChain(ServletRequest request, ServletResponse response, FilterChain origChain) {
    //获取当前url匹配的过滤器链
    FilterChain chain = getExecutionChain(request, response, origChain);
    //执行过滤器链中过滤器
    chain.doFilter(request, response);
}

protected FilterChain getExecutionChain(ServletRequest request, ServletResponse response, FilterChain origChain) {
    FilterChain chain = origChain;
	//获取过滤器链解析器，即创建的PathMatchingFilterChainResolver对象
    FilterChainResolver resolver = getFilterChainResolver();
    if (resolver == null) {
        log.debug("No FilterChainResolver configured.  Returning original FilterChain.");
        return origChain;
    }
	// 调用其getChain方法，根据URL匹配相应的过滤器链
    FilterChain resolved = resolver.getChain(request, response, origChain);
    if (resolved != null) {
        log.trace("Resolved a configured FilterChain for the current request.");
        chain = resolved;
    } else {
        log.trace("No FilterChain configured for the current request.  Using the default.");
    }
    return chain;
}

public void doFilterInternal(ServletRequest request, ServletResponse response, FilterChain chain){
    Exception exception = null;
    try {
        //前置通知，判断该过滤链是否支持该请求
        boolean continueChain = preHandle(request, response);
        if (continueChain) {
            //执行过滤器链
            executeChain(request, response, chain);
        }
        //后置通知
        postHandle(request, response);
    } catch (Exception e) {
        exception = e;
    } finally {
        //最终通知
        cleanup(request, response, exception);
    }
}

protected boolean preHandle(ServletRequest request, ServletResponse response) throws Exception {
    for (String path : this.appliedPaths.keySet()) {
// If the path does match, then pass on to the subclass implementation for specific checks
//(first match 'wins'):
        if (pathsMatch(path, request)) {
log.trace("Current requestURI matches pattern '{}'.  Determining filter chain execution...", path);
            Object config = this.appliedPaths.get(path);
            return isFilterChainContinued(request, response, path, config);
        }
    }
    //no path matched, allow the request to go through:
    return true;
}

private boolean isFilterChainContinued(ServletRequest request, ServletResponse response,
                                       String path, Object pathConfig) throws Exception {
    return onPreHandle(request, response, pathConfig);
}

public boolean onPreHandle(ServletRequest request, ServletResponse response, Object mappedValue) throws Exception {
    //如果isAccessAllowed方法返回false，则会执行onAccessDenied方法
    return isAccessAllowed(request, response, mappedValue) || onAccessDenied(request, response, mappedValue);
}

protected boolean isAccessAllowed(ServletRequest request, ServletResponse response, Object mappedValue) {
    return super.isAccessAllowed(request, response, mappedValue) ||
            (!isLoginRequest(request, response) && isPermissive(mappedValue));
}

protected boolean isAccessAllowed(ServletRequest request, ServletResponse response, Object mappedValue) {
    Subject subject = getSubject(request, response);
    return subject.isAuthenticated();
}

protected boolean onAccessDenied(ServletRequest request, ServletResponse response) throws Exception {
    //是否为登陆请求
    if (isLoginRequest(request, response)) {
        //是否是POST请求
        if (isLoginSubmission(request, response)) {
            if (log.isTraceEnabled()) {
                log.trace("Login submission detected.  Attempting to execute login.");
            }
            return executeLogin(request, response);
        } else {
            if (log.isTraceEnabled()) {
                log.trace("Login page view.");
            }
            //allow them to see the login page ;)
            return true;
        }
    } else {
        if (log.isTraceEnabled()) {
            log.trace("Attempting to access a path which requires authentication.  Forwarding to the " +
                      "Authentication url [" + getLoginUrl() + "]");
        }
		//执行跳转到登陆界面login.jsp
        saveRequestAndRedirectToLogin(request, response);
        return false;
    }
}

protected boolean executeLogin(ServletRequest request, ServletResponse response) throws Exception {
    AuthenticationToken token = createToken(request, response);
    if (token == null) {
        String msg = "createToken method implementation returned null. A valid non-null AuthenticationToken " +
                "must be created in order to execute a login attempt.";
        throw new IllegalStateException(msg);
    }
    try {
        Subject subject = getSubject(request, response);
        subject.login(token);
        //重定向到上次访问的url,过滤链不再执行
        return onLoginSuccess(token, subject, request, response);
    } catch (AuthenticationException e) {
        //过滤链继续执行，返回到登陆界面
        return onLoginFailure(token, e, request, response);
    }
}

public void login(AuthenticationToken token) throws AuthenticationException {
    clearRunAsIdentitiesInternal();
    //securityManager 登录
    Subject subject = securityManager.login(this, token);

    PrincipalCollection principals;

    String host = null;

    if (subject instanceof DelegatingSubject) {
        DelegatingSubject delegating = (DelegatingSubject) subject;
        //we have to do this in case there are assumed identities - we don't want to lose the 'real' principals:
        principals = delegating.principals;
        host = delegating.host;
    } else {
        principals = subject.getPrincipals();
    }

    if (principals == null || principals.isEmpty()) {
        String msg = "Principals returned from securityManager.login( token ) returned a null or " +
            "empty value.  This value must be non null and populated with one or more elements.";
        throw new IllegalStateException(msg);
    }
    this.principals = principals;
    this.authenticated = true;
    if (token instanceof HostAuthenticationToken) {
        host = ((HostAuthenticationToken) token).getHost();
    }
    if (host != null) {
        this.host = host;
    }
    Session session = subject.getSession(false);
    if (session != null) {
        this.session = decorate(session);
    } else {
        this.session = null;
    }
}

public Subject login(Subject subject, AuthenticationToken token) throws AuthenticationException {
    AuthenticationInfo info;
    try {
        //关键逻辑
        info = authenticate(token);
    } catch (AuthenticationException ae) {
        try {
            onFailedLogin(token, ae, subject);
        } catch (Exception e) {
            if (log.isInfoEnabled()) {
                log.info("onFailedLogin method threw an " +
                         "exception.  Logging and propagating original AuthenticationException.", e);
            }
        }
        throw ae; //propagate
    }
    //认证成功，重新创建subject
    Subject loggedIn = createSubject(token, info, subject);
    //处理rememberme逻辑
    onSuccessfulLogin(token, info, loggedIn);

    return loggedIn;
}

public AuthenticationInfo authenticate(AuthenticationToken token) {
    return this.authenticator.authenticate(token);
}

protected AuthenticationInfo doAuthenticate(AuthenticationToken authenticationToken) throws AuthenticationException {
       assertRealmsConfigured();
       Collection<Realm> realms = getRealms();
       if (realms.size() == 1) {
           return doSingleRealmAuthentication(realms.iterator().next(), authenticationToken);
       } else {
           return doMultiRealmAuthentication(realms, authenticationToken);
       }
   }

protected AuthenticationInfo doMultiRealmAuthentication(Collection<Realm> realms, AuthenticationToken token) {
    //多realm下的认证策略默认实现为AtLeastOneSuccessfulStrategy
    AuthenticationStrategy strategy = getAuthenticationStrategy();
    AuthenticationInfo aggregate = strategy.beforeAllAttempts(realms, token);
    for (Realm realm : realms) {
        aggregate = strategy.beforeAttempt(realm, token, aggregate);
        if (realm.supports(token)) {
            //关键实现方法
            AuthenticationInfo info = realm.getAuthenticationInfo(token);
            aggregate = strategy.afterAttempt(realm, token, info, aggregate, t);
        } else {
            log.debug("Realm [{}] does not support token {}.  Skipping realm.", realm, token);
        }
    }
    aggregate = strategy.afterAllAttempts(token, aggregate);
    return aggregate;
}

public final AuthenticationInfo getAuthenticationInfo(AuthenticationToken token) throws AuthenticationException {
    AuthenticationInfo info = getCachedAuthenticationInfo(token);
    if (info == null) {
        //覆盖实现核心认证信息
        info = doGetAuthenticationInfo(token);
        if (token != null && info != null) {
            cacheAuthenticationInfoIfPossible(token, info);
        }
    }
    if (info != null) {
        assertCredentialsMatch(token, info);
    }
    return info;
}

public class ShiroRealmA extends AuthenticatingRealm {
    @Override
    protected AuthenticationInfo doGetAuthenticationInfo(AuthenticationToken token) throws AuthenticationException {
        System.out.println("===>ShiroRealmA<=====" + JSON.toJSONString(token));
        /**
         * 1. 吧AuthenticationToken转为usernamepasswordtoken
         * 2. 获取用户名与密码
         * 3. 调用数据库的方法
         * 4. 根据数据库用户情况抛出异常或构建AuthenticationInfo
         */
        UsernamePasswordToken usernamePasswordToken = (UsernamePasswordToken) token;
        String username = usernamePasswordToken.getUsername();
        // 数据库获取的密码，，前端加密 密码加密
        //盐值一般是唯一值，可以是用户名
        ByteSource salt = ByteSource.Util.bytes(username);
        Object credentials = "123";
        Object credentialsMD5 = new SimpleHash("MD5", credentials, salt, 2);

        if ("zs".equals(username)) {
            return new SimpleAuthenticationInfo(username,credentialsMD5, salt, this.getName());
        } else {
            throw new AuthenticationException();
        }
    }
}

public boolean isAccessAllowed(ServletRequest request, ServletResponse response, Object mappedValue) throws IOException {
    Subject subject = getSubject(request, response);
    //访问需要的权限
    String[] perms = (String[]) mappedValue;
    //subject判断是否有权限
    boolean isPermitted = true;
    if (perms != null && perms.length > 0) {
        if (perms.length == 1) {
            if (!subject.isPermitted(perms[0])) {
                isPermitted = false;
            }
        } else {
            if (!subject.isPermittedAll(perms)) {
                isPermitted = false;
            }
        }
    }
    return isPermitted;
}

public boolean isPermitted(PrincipalCollection principals, String permission) {
    assertRealmsConfigured();
    for (Realm realm : getRealms()) {
        if (!(realm instanceof Authorizer)) continue;
        // 调用Realm的isPermitted方法
        if (((Authorizer) realm).isPermitted(principals, permission)) {
            return true;
        }
    }
    return false;
}

public boolean isPermitted(String permission) {
    return hasPrincipals() && securityManager.isPermitted(getPrincipals(), permission);
}

public boolean isPermitted(PrincipalCollection principals, String permissionString) {
    return this.authorizer.isPermitted(principals, permissionString);

public boolean isPermitted(PrincipalCollection principals, String permission) {
      Permission p = getPermissionResolver().resolvePermission(permission);
      return isPermitted(principals, p);
  }

  public boolean isPermitted(PrincipalCollection principals, Permission permission) {
      AuthorizationInfo info = getAuthorizationInfo(principals);
      return isPermitted(permission, info);
  }

protected AuthorizationInfo getAuthorizationInfo(PrincipalCollection principals) {

    AuthorizationInfo info = null;
	//缓存中获取授权信息
    Cache<Object, AuthorizationInfo> cache = getAvailableAuthorizationCache();
    if (cache != null) {
        Object key = getAuthorizationCacheKey(principals);
        info = cache.get(key);
    }
    if (info == null) {
        // 继承覆盖实现获取授权信息
        info = doGetAuthorizationInfo(principals);
        if (info != null && cache != null) {
            Object key = getAuthorizationCacheKey(principals);
            cache.put(key, info);
        }
    }

    return info;
}

protected boolean onAccessDenied(ServletRequest request, ServletResponse response) throws IOException {
    Subject subject = getSubject(request, response);
    //未登陆，跳转到登陆界面
    if (subject.getPrincipal() == null) {
        saveRequestAndRedirectToLogin(request, response);
    } else {
        //登陆未授权、返回未授权界面或者401状态码
        String unauthorizedUrl = getUnauthorizedUrl();
        if (StringUtils.hasText(unauthorizedUrl)) {
            WebUtils.issueRedirect(request, response, unauthorizedUrl);
        } else {
            WebUtils.toHttp(response).sendError(HttpServletResponse.SC_UNAUTHORIZED);
        }
    }
    return false;
}

protected boolean onAccessDenied(ServletRequest request, ServletResponse response) throws Exception {
    //是否为登陆请求
    if (isLoginRequest(request, response)) {
        //是否是post请求
        if (isLoginSubmission(request, response)) {
            return executeLogin(request, response);
        } else {
            return true;
        }
    } else {
        saveRequestAndRedirectToLogin(request, response);
        return false;
    }
}

protected boolean executeLogin(ServletRequest request, ServletResponse response) throws Exception {
    AuthenticationToken token = createToken(request, response);
    try {
        Subject subject = getSubject(request, response);
        subject.login(token);
        return onLoginSuccess(token, subject, request, response);
    } catch (AuthenticationException e) {
        return onLoginFailure(token, e, request, response);
    }
}

protected boolean isAccessAllowed(ServletRequest request, ServletResponse response, Object mappedValue) {
        if (isLoginRequest(request, response)) {
            return true;
        } else {
            Subject subject = getSubject(request, response);
            return subject.getPrincipal() != null;
        }
}

protected boolean onAccessDenied(ServletRequest request, ServletResponse response) throws Exception {
        saveRequestAndRedirectToLogin(request, response);
        return false;
}
